ENGINE BRAND
KOHLER
FUEL TYPE
FUEL TYPE
TRANSMISSION
HYDRO-GEAR ZT-3200
DISPLACEMENT
725
GROUND SPEED (MPH)
9
CLUTCH
ELECTROMAGNETIC
DECK SIZE
42" & 48"
DECK THICKNESS
10 GA w/ 11 GAUGE REINFORCED SPINDLE MOUNT
CRANKSHAFT
VERTICAL
SPINDLE SPECS
FORGED ALUMINUM HOUSING w/ SEALED BALL BEARINGS
BLADE SPECS
.203 STRAIGHTENED & HARDENED STEEL
CUTTING HEIGHT
1.5" -4.5"
HORSEPOWER
22 EFI
FUEL CAPACITY
10 GAL
COOLING SYSTEM
AIR
SEAT TRACK
6" LOCKING TRACK
REAR TIRES
23"x 8.5" - 12R
OVERALL LENGTH
74 3/4"
STEERING CONTROLS
1.5" DIA. GRIPS, ADJUSTABLE, DAMPENED
FRONT TIRES
13" x 5" x 6" PNEUMATIC
ROPS HEIGHT (UP/DOWN)
70" / 46.3"
ARM REST
PADDED ARM RESTS
SMART HOUR METER
STANDARD
BLADE TIP SPEED
17,500 ft/min
COVER
DURABLE SEWN VINYL COVER
BACKREST
20" SEAT BACK
PARKING BRAKE
INTEGRATED INTO STEERING LEVERS
WEIGHT
910 LBS
ACRES PER HOUR
4
DISCHARGE CHUTE
RUBBER DISCHARGE CHUTE
CASTER FORKS
SEALED BALL BEARING
CASTER FORKS
3/8" FORMED
FRAME GAUGE
7 GAUGE
FEATURES
REINFORCED FORMED FRAME
OVERALL WIDTH
UP 44.75" / DOWN 58"
STORAGE
CUP HOLDER, DEEP STORAGE TRAY
MAINTENANCE
4 GREASE POINTS
BATTERY
12 VOLT
